Spoke Load Cell 30kg 50kg 100kg 200kg 300kg 500kg 800kg 1T Weighing Sensor + LCD Display Indicator for Platform Scale for DIY Electronic(50kg Indicator)

1pcs S type weighing sensor + 1pcs load cell Indicator indicator we have two size :load cell display instrument weighing pressure digital display instrument S weight sensor 2 way outputwe have :96×48×112 and 160 X 80 * 125 two size ,please leave a message which you need .or we will default 96×48×112.Sensitivity: 2.0 ± 0.05mV / VSensitivity coefficient: ± 0.03% F.S / 10CNonlinear: ± 0.03% F.SHysteresis: ± 0.03% F.SRepeatability: ± 0.03% F.SCreep: ± 0.05% F.S / 30minZero output: ± 1% F.SZero temperature coefficient: ± 0.03% F.S / 10COperating temperature range: -20 ~ 80CInput Resistance: 350 ± 20Output Resistance: 350 ± 5Insulation resistance: 5000M (50VDC)supply voltage range : 5-15V

• 1. Our product features a highly accurate S type weighing sensor with a load cell indicator. With a sensitivity of 2.0 ± 0.05mV/V and a sensitivity coefficient of ± 0.03% F.S/10C
• 2. We offer two size options for the load cell display instrument - 96×48×112 and 160 X 80 * 125
• 3. Our Spoke Load Cell Weighing Sensor is designed to withstand extreme temperatures, operating reliably in a range of -20 ~ 80C
• 4. With a overload capacity of 150% F.S and an insulation resistance of 5000M (50VDC)
• 5. The Spoke Load Cell Weighing Sensor requires a supply voltage range of 5-15V, making it compatible with a wide range of power sources
